| MODEL | 61503 |
| Power Rating | 1500VA |
| Phase | 1 |
| Voltage Range | 0-150V/0-300V/ Auto |
| Frequency | DC. 15Hz~1kHz |
| Parallel Capability | Not Available |
Caratteristiche:
-Output Rating :
-Output Rating :
- Power : 500VA (61501), 1000VA (61502) 1500VA (61503),
2000VA (61504) 4000VA (61505) - Voltage range: 0-150V/0-300V/Auto
- Compact size and weight attributable to advance PWM technology
- AC+DC output mode for voltage DC offset simulation
- Programmable slew rate setting for changing voltage and frequency
- Low output impedance for testing IEC 61000-3-2 ( 61505 )
- Programmable output impedance for testing IEC 61000-3-3
- LIST, PULSE, STEP mode function for testing power line disturbance (PLD) simulation capability
- IEC 61000-4-11 voltage dips, short and variation simulation
- Harmonics, inter-harmonics waveform synthesizer for testing IEC 61000-4-13
- Programmable voltage, current limit
- Comprehensive measurement capability including current harmonics
- High output current crest factor, ideal for inrush current testing
- Turn on, turn off phase angle control
- TTL signal which indicates output transient
- Analog programmable interface
- 3 units combined to 3-phase power output
- Easy-use software for operation and IEC regulation test
- Optional GPIB, RS-232, LAN and USB interface
