Data logger Rigol M302 Mainframe(including 6.5 DMM and MUX20)

da Rigol
€1.585,00

Multimetro scanner composto da:

  • mainframe
  • scheda multimetro 6 digit e 1/2 MC3065
  • scheda multiplexer 20 canali MC3120
  • morsettiera M3TB20

Mainframe Specs

M302

Number of Slots

5 (DMM and MC3120 use one of these slots each)

Included Modules

MC3065 DMM and MC3120 Module

Interfaces

USB Host & Device, LAN (LXIC), GPIB, RS-232

DMM Specs

Please download M300 datasheet or User’s Guide for complete

Model MC3065 DMM Module specs

Switch Specs

Multiplexer

Actuator

Matrix

General

MC3120

MC3132

MC3164

MC3324

MC3416

MC3648

Number of Channels

20

32

64

20 Voltage+4 Current

16

4×8

2/4 wire[1]

2/4 wire[1]

1 wire [2]

2/4 wire [3]

SPDT

2 wire

Connect to DMM Module?

Yes

Yes

Yes

Yes

No

No

Scanning Speed[4]

60Ch/s

60Ch/s

60Ch/s

60Ch/s

——

——

Open/Close Speed

200Ch/s

200Ch/s

200Ch/s

200Ch/s

200Ch/s

200Ch/s

Maximum Input

Voltage (DC, AC rms)

300Vrms

300Vrms

300Vrms

300Vrms

300Vrms

300Vrms

Current (DC, AC rms)

1Arms

1Arms

1Arms

1Arms

2Arms

1Arms

Power (W, VA)

50VA

50VA

50VA

50VA

60VA

50VA

Isolation (ch-ch, ch-earth) (DC, AC rms)

300Vrms

300Vrms

300Vrms

300Vrms

300Vrms

300Vrms



Manuals:

M300_Datasheet
M300_User_Manual
M300_Selection_Guide
M300_Quick_Guide
M300_Programming_Guide
