| MODEL | 66203 |
|
Canali |
3 |
Caratteristiche：
- Voltage Ranges : 15/30/60/150/300/600 Vrms,1200Vrms (optional kit)
- Current Ranges : 0.005/0.02/0.05/0.2/0.5/2/5/20 Arms
- Frequency Range : DC, 15Hz~10kHz
- Embedded high speed DSP, 16 bits Analog/Digital converters
- Half rack size, up to 4 input modules
- Supports various single and 3 phase wiring configurations (see diagram)
- Supports external shunt and CT for higher current applications
- 5 mA minimum current range & 0.1mW power resolution
- Meets ENERGY STAR / EN 50564 / IEC 62301 / ErP / SPEC Power
- Includes accumulated energy methods for unstable power measurement
- User-define criteria provides automatic PASS/FAIL indications
- Dual current shunt design provides high accuracy over a wide current range
- THD and user-specify order distortion measurement
- Inrush current and energy measurements
- Voltage / Current harmonics measurements up to 50 orders
- Support ultra high precision DCCT 60A/200A optional kit for high current measurement application
