Oscilloscopio digitale a basso costo , 50 Mhz larghezza di banda , frequenza di campionamento 1GSa/s, memoria 1Mpts,
2 canali analogici, ottimo rapporto qualita' prezzo . La spedizione include 2 sonde , un cavo USB , pc software , adattatore alimentazione .
Specifiche tecniche:
Model
|
DS1052E
|
|||
Bandwidth
|
50 MHz
|
|||
Analog Channels
|
2
|
|||
Vertical Sensitivity
|
2 mV/div - 10V/div
|
|||
Real-time Sample Rate
|
1 GSa/s(each channel),500 MSa/s(dual channels)
|
|||
Equivalent Sample Rate
|
10 GSa/s
|
|||
Memory Depth
|
Mode
|
capture rate
|
common
|
long memory
|
one channel
|
1 GSa/s
|
16 kpts
|
N/A
|
|
500 MSa/s
|
16 kpts
|
1 Mpts
|
||
dual channels
|
500 MSa/s
250 MSa/s
or less |
8 kpts
8 kpts
|
N.A.
512 kpts
|
|
Standard Interface
|
USB Host & Device, RS-232, P/F Out
|
|||
Vertical Resolution
|
8 bits
|
|||
Math
|
+, -, ×, FFT
|
|||
Max Input Voltage
|
All inputs 1MΩ‖15pF 300 V RMS CATⅠ
|
|||
Cursor Measurements
|
Manual, Track and Auto Measure modes
|
